Ronan X76CTM - Manual (Page 27)

26
X76CTM TYPICAL
INSTALLATION DRAWING
SERIES
X76CTM-4X
INSIDE WALL
WIRE CONDUIT
WIRE FROM
PROBE
WATERTIGHT
WIRE
CONNECTOR
SHIELD
GROUND
WIRE CONDUIT
JUNCTION BOX
(COVER
REMOVED)
OPTIONAL WIRE
TO NEXT PROBE
PRODUCT
WATER
TANK
VAPOR
SEAL
CABLE
GRIP
OUTSIDE
WALL
GROUND LEVEL
MANHOLE
PROBE WIRE
CABLE GRIP
950 CAP
4" PIPE RISER
4" TANK
BUSHING
16" MIN.
950 4" TOP
SEAL ADAPTOR
PROBE CODE
REP. RATE/SPEED
OF WIRE
950 -_ _ _ B
951 -_ _ _ B
PROBE
NON-HAZARDOUS HAZARDOUS
"WATERPROOF JUNCTION"
DETAIL A
WATERPROOF
JUNCTION BOX
(SEE DETAIL A)
NOTE: Reference Ronan Engineering
Drawing Number X76D510.
