the times, the time is cleared and assumed not to
be used for filtering. If the event is tank specific, a
prompt for selecting the tank will be displayed
(some events like contact, login, and logout are not
tank related). After selecting the filter, the filtered
events will be browsed the same as F100.
10.0 FUNCTION CODES
The functions available for the X76CTM are listed in
Figure 2 by function number, description, and page
location for detailed programming information.
However, Section 10.0 has been outlined in the
proper programming sequence.
To execute a function, press the
.
key. The follow-
ing message appears:
Select function
Or scroll with (HI, LO) key
Enter the function code (if known) or use [HI] and
[LO] keys to scroll through the available functions.
The function appears with the description on the
second line of the LCD. When the desired function
is selected, press [ENT.].
Use the [DISPLAY] key at any time to cancel the
action and return to the current default display.
. .
7021, Beginning Initial Programming
Each X76CTM is factory tested prior to shipping.
During the testing process many of the systems
functions are programmed. If this information is not
erased or reprogrammed, it may effect the perfor-
mance of the system. It is suggested that the mem-
ory be cleared prior to programming the system for
the first time or if making substantial changes to the
system’s programming.
. .
94, Station Name
This function sets the station name. The station
specific data is the station name, city, and address.
The device is programmed at the factory with the
manufacturer’s name, address, and city.
Station Name
Ronan Engineering Company
. .
95, Station Address
Sets the station address.
Station address
21200 Oxnard St.
Function Description Page No.
Delivery Threshold
Set Up Contact [HI, LO]
Select Probe Type
Date & Time Format
[HI, LO]
Enter Tank Ullage %
Enter RTD-S Number
58 Software Version
62 Enter Code For:
63 Set Up Communications
66 Display Tank and
Contact Status
68 Manifolds to #12345678
72 Initial Product Level
73 Initial Water Level
74 Tank Model [HI, LO]
75 Leak Detect Threshold
76 High Water Level Alarm
78 Select Product [HI, LO]
79 Theft Detect Threshold
81 Set Up Relay [HI, LO]
82 Set Up Tank Alarm
84 High-High Volume Alarm
91 Enter Date & Time:
92 Enter Product Expansion
93 Select Units to Use
94 Station Name
95 Station Address
96 Station City
97 Enter Product Name
100 Browse Events
101 Event Query Filter
103 Print Report: [HI, LO]
184 Low-Low Volume Alarm
290 Disable Tank
291 Enable Tank
292 Enable Theft Monitor
7021 Beginning Initial Programming
Figure 2: Function Codes.
9
43
44
45
46
47
48
12
14
11
10
12
11
11
11
10
12
13
12
13
10
11
10
9
9
9
12
16
16
16
14
11
11
19
9
14
13
14
15
15
15
13
. .
96, Station City
Sets the stations city, state and zip code.
Station City
Woodland Hills CA 91367
