Figure 2 figure 3 – Reese 56010 OUTBOARD CUSTOM QUICK INSTALL KIT User Manual
Page 7
©
2012, 2013 Cequent Performance Products, Inc.
Rev. A
56010N
6/24/13
7
Caisse de 6,5 pi seulement : couper
le prolongement fixé aux poutres
de soutien de la caisse.
Figure 2
Figure 3
DIMENSIONS SPÉCIFIQUES POUR ENSEMBLE DE TRAVERSES DE MONTAGE 30153
AVANT DU
VÉHICULE
Plateforme longue 30
1/8 po
Plateforme courte 28
1/8 po
Approx. 1 9/16 po (plateforme longue)
Approx. 1 7/16 po (plateforme courte)
RA
NG
É
E
1
RA
NG
É
E
2
RA
NG
É
E
3
RA
NG
É
E
4
BOULON
CENTRAL
BOULON
CENTRAL
℄
de l'essieu
℄
de l'attelage
TRAVERSE DE
MONTAGE
MANCHON
SUPPORT D'ATTELAGE/CURSEUR/COL DE
CYGNE (SUPPORT D'ATTELAGE ILLUSTRÉ)
Support de la plateforme
de camionnette
CADRE
