Figure 2 figure 3 – Reese 56010 OUTBOARD CUSTOM QUICK INSTALL KIT User Manual
Page 3
©
2012, 2013 Cequent Performance Products, Inc.
Rev. A
56010N
6/24/13
3
6.5’ truck boxes only - cut
off the extension attached
to the truck box support
beams.
Figure 2
Figure 3
DIMENSIONS SPECIFIC FOR RAIL KIT 30153
FRONT OF VEHICLE
30 1/8” LONG BED
28 1/8” SHORT BED
APPROX. 1-9/16” LONGBED
APPROX. 1-7/16” SHORTBED
ROW
1
ROW
2
ROW
3
ROW
4
CENTER BOLT
CENTER BOLT
℄
OF AXLE
℄
OF HITCH
MOUNTING RAIL
BUSHING
HITCH SUPPORT / SLIDER / GOOSE
(HITCH SUPPORT SHOWN)
TRUCK BED SUPPORT
FRAME
Mark and centerpunch
Typical (4) places
