2-12

MACHETE

SERVICE BULLETIN No. 971903

Alamo Industrial Technical Services Department

1502 East Walnut

Seguin, Texas 78155

830-372-2708

Turning Arm - King Pin Upgrades:

Subject:

Boom Hinge Point Pin Upgrades. These repairs are covered in detail on Technical Information
Bulletins # 041797-1 and # 041797-2. These Technical Information Bulletins must be consulted
for detailed instructions for performing the following repairs. Also use Instruction Sheet that will
be included with the Pin Kits

Service Required:

See Technical Information Bulletins # 041797-1 and # 041797-2 for detailed instructions on how
to perform these modifications.

Caution must always be used when installing new bushing and when aligning the pins. Do Not
try to align the pins by hitting it with a hammer, See operators manual for correct way to align
pins and install bushings. It is recommended that bushings be installed with a bushing driver,
these Bushing drivers are available from Alamo Industrial (See Technical Information Bulletin
# 032697).

Parts Required:

Turning Arm - King Pin Replacement Kits:

(Qty use 1 each)

Part No.

Description

02972211

Turning Arm Kit

02967679

Lift Cyl. Pin Kit, Barrel End

02967675

Swing Cyl. Pin Kit, Rod End

02967689

Main Pin Replacement

Note: Instruction Sheet is included in Kit. Check with Service Bulletin 972103 (970002A) and

971903 (970001A) as these service bulletins use some of the same parts and cover some of the same
upgrades, so when ordering parts for this service bulletin check so duplicate parts (kits) are not ordered.

Models:

Machete Boom Mowers

Manufactured prior to Mar. 1997

Date:

Mar. 19, 1997

Bulletin No:
971903
(Old # 970001A)

Parts:

100 % at Dealer Net

Labor:

2.5 hrs. at Dealer registered
Shop Rate

Termination Date:

Sep. 1, 1997

Old Parts Disposition:

Hold any removed parts
for warranty decision

Continued Next Page
