ADSP-21364 EZ-KIT Lite Evaluation System Manual I-1
I INDEX
A
AD15-8 pins, 2-3 , 2-7
AD1835, CAD and DAC
master clock (MCLK), 1-8 , 2-6
AD1835A, CAD and DAC
configuration registers, 1-9 , 2-6
DAI interface, 1-8 , 2-5
master/slave modes, 1-9 , 2-10
setup switch (SW7), 2-10
SPI interface, 2-6 , 2-7
AD7-0 (LED8-1) pins, 1-11 , 2-7 , 2-11 , 2-14
ADC_DATA pins, 2-10
ALE pins, 2-3 , 2-11
analog audio, See audio, AD1835A
analog-to-digital converters (ADCs), See
AD1835A
architecture, of this EZ-KIT Lite, 2-2
audio
in RCA connector (J4), 1-9 , 2-17
interface, xi , 1-8
oscillators, 2-5 , 2-10
out RCA connector (J5), 2-17
B
background telemetry channel (BTC), 1-12
bill of materials, A-1
board schematic, B-1
boot
configuration pins (BOOTCFG1-0), 2-12
modes, 2-3 , 2-12
C
CLKCFG1-0 pins, 2-3 , 2-12
CLKIN pins, 2-3
clock
multiplier ratios, 2-12
routing, 2-10
codecs, See AD1835A
configuration, of this EZ-KIT Lite,
1-3
connectors
diagram of locations, 1-3 , 2-16
J1-3 (expansion interface), 2-4 , 2-6 , 2-7 , 2-16
J4 (audio in RCA), 1-9 , 2-17
J5 (audio out RCA), 1-9 , 2-17
J6 (headphone out), 1-9 , 2-17
J7 (power), 1-4 , 2-18
J8-9 (S/PDIF in coax), 2-18
P2 (SPI header), 2-6 , 2-19
P3 (DAI header), 2-6 , 2-19
ZJ1 (USB), 1-4 , 2-19
ZP4 (JTAG), 2-8 , 2-20
conventions, manual, xx
core
clock rates, 2-12
frequency, 2-3
to CLKIN ratios, 2-12
voltage, 2-2
customer support, xiv
