ADSP-21364 EZ-KIT Lite Evaluation System Manual 2-17
ADSP-21364 EZ-KIT Lite Hardware Reference
Audio In RCA Connector (J4)
Audio Out RCA Connector (J5)
Headphone Out Jack (J6)
Part Description Manufacturer Part Number
90-position 0.05” spacing,SMT SAMTEC SFC-145-T2-F-D-A
Mating Connectors
90-position 0.05” spacing
(through hole) SAMTEC TFM-145-x1 series
90-position 0.05” spacing
(surface mount) SAMTEC TFM-145-x2 series
90-position 0.05” spacing
(low cost) SAMTEC TFC-145 series
Part Description Manufacturer Part Number
Two-channel right angle RCA jack SWITCHCRAFT PJRAS1X2S02X
Mating Cable
Two-channel RCA interconnect cable MONSTER CABLE BI100-1M
Part Description Manufacturer Part Number
Six-channel right angle RCA jack SWITCHCRAFT PJRAS4X2U01X
Mating Cable
Two-channel RCA interconnect cable MONSTER CABLE BI100-1M
Part Description Manufacturer Part Number
3.5 mm stereo jack A/D ELECTRONICS ST-323-5
