ADSP-21364 EZ-KIT Lite Evaluation System Manual
2-13
ADSP-21364 EZ-KIT Lite Hardware Reference
Loop-Back Test Switch (SW11)
The loop-back test switch (
SW11
) is located at the bottom of the board.
This switch is used for testing; all switch positions should remain
OFF
.
LEDs and Push Buttons
This section describes the functionality of the LEDs and push buttons.
shows the LED and push button locations.
Figure 2-6. LED and Push Button Locations
