Connectors
2-18 ADSP-21364 EZ-KIT Lite Evaluation System Manual
Power Jack (J7)
The power connector ( J7 ) provides all of the power necessary to operate
the EZ-KIT Lite board.
The power connector supplies DC power to the EZ-KIT Lite board.
Table 2-7 shows the power supply specifications.
S/PDIF Coax Connectors (J8 and J9)
Part Description Manufacturer Part Number
2.5 mm power jack SWITCHCRAFT
DIGI-KEY RAPC712X
RAPC712X-ND
Mating Power Supply (shipped with EZ-KIT Lite)
7V power supply CUI STACK DMS070214-P6P-SZ
Table 2-7. Power Supply Specifications
Terminal Connection
Center pin +7 [email protected]
Outer ring GND
Part Description Manufacturer Part Number
Coaxial SWITCHCRAFT PJRAN1X1U01X
Mating Cable
Two-channel RCA interconnect
cable MONSTER CABLE BI100-1M
