ADSP-21364 EZ-KIT Lite Evaluation System Manual xi
Preface
• Analog audio interface
D AD1835A codec
D 4x2 RCA phono jack for 4 channels of stereo output
D 2x1 RCA phono jack for 1 channel of stereo input
D Headphone jack for 1 channel stereo output
• Digital audio interface
D RCA phono jack output
D RCA phono jack input
• LEDs
D 11 LEDs: 1 power (green), 1 board reset (red), 1 USB mon-
itor (amber), and 8 general purpose (amber)
• Push buttons
D 5 push buttons: 1 reset, 2 connected to DAI,
2 connected to the
FLAG pins of the processor
• Expansion interface (type A)
D Parallel port, FLAG s, DAI, SPI
• Other features
D JTAG ICE 14-pin header
D 0-ohm resistors for processor current measurement
D SPI header
D DAI header
The EZ-KIT Lite board has a total of 1 MB of parallel flash memory and
2 MB of SPI flash memory. The flash memories can store user-specific
boot code, allowing the board to run as a stand-alone unit. For more
