LEDs and Push Buttons
2-14 ADSP-21364 EZ-KIT Lite Evaluation System Manual
General Purpose LEDs (LED8–1)
Eight general-purpose LEDs connect to the processor through a latch on
signals
AD7–0 . The LEDs can be accessed by writing to the FLAG registers
or by writing to a memory address. Refer to “LEDs and Push Buttons” on
page 1-10 for more information.
Reset LED (LED9)
When LED9 is lit (red), the master reset of all the major ICs is active.
Power LED (LED10)
When LED10 is lit (green), it indicates that power is being supplied to the
board properly.
USB Monitor LED (ZLED3)
The USB monitor LED ( ZLED3 ) indicates that USB communication has
been initialized successfully, and you can connect to the processor using a
VisualDSP++ EZ-KIT Lite session. Once the USB cable is plugged into
the board, it takes approximately 15 seconds for the USB monitor LED to
light. If the LED does not light, try cycling power on the board and/or
reinstalling the USB driver (see the VisualDSP++ Installation Quick Refer-
ence Card).
L
When VisualDSP++ is actively communicating with the EZ-KIT
Lite target board, the LED can flicker, indicating communications
handshake.
