The
CLKIN
pin of the processor connects to a 24.576 MHz oscillator. The
core frequency of the processor is derived by multiplying the frequency at
the
CLKIN
pin by a value determined by the state of the processor pins,
CLKCFG1
and
CLKCFG0
. The value at these pins is determined by the state of
the
SW10
switch (see
“Boot Mode and Clock Ratio Select Switch (SW10)”
). By default, the EZ-KIT Lite provides a core frequency of
147.456 MHz. It is possible to increase the speed of the processor by
changing the value of the
PMCTL
register.
The
SW10
switch also configures the boot mode of the processor. The
EZ-KIT Lite is capable of parallel port boot and SPI master boot. By
default, the EZ-KIT Lite boots from the parallel port. For information
about configuring the boot modes, see
Select Switch (SW10)” on page 2-12
.
Parallel Port
The parallel port (PP) of the ADSP-21364 processor consists of a 16-bit
multiplex address/data memory bus (
AD15–0
) and an address latch-enable
pin (
ALE
). The interface does not have any memory select pins; these sig-
nals must be generated by decoding the address.
The PP connections to the EZ-KIT Lite are shown in
connects to an 8-bit parallel flash memory, an 8-bit SRAM memory, and
eight general-purpose LEDs. The upper three address bits connect to a
3-to-8 decoder, providing eight memory select pins. See
for more information about accessing the flash and
SDRAM memories.
Because the PP is a multiplexed address/data memory bus, two 8-bit
latches are used to latch the upper address bits. Additional latch is used to
drive the LEDs. The latter allows the LED values to be written to as if
they were at a memory location. For more information about using the
LEDs, refer to the
