ADSP-21364 EZ-KIT Lite Evaluation System Manual 1-7
Using ADSP-21364 EZ-KIT Lite
Evaluation License Restrictions
The ADSP-21364 EZ-KIT Lite installation is part of the VisualDSP++
installation. The EZ-KIT Lite is a licensed product that offers an unre-
stricted evaluation license for the first 90 days. Once the initial
unrestricted 90-day evaluation license expires:
1. VisualDSP++ allows a connection to the ADSP-21364 EZ-KIT
Lite via the USB Debug Agent interface only. Connections to sim-
ulators and emulation products are no longer allowed.
2. The linker restricts a users program to 10922 words of internal
memory for code space with no restrictions for data space.
Refer to the VisualDSP++ Installation Quick Reference Card for details.
External Memory
The EZ-KIT Lite contains three types of memory: parallel flash (1 MB),
SPI flash (2 MB) and SRAM (512 Kbit). The flash memories can store
user-specific boot code, allowing the board to run as a stand-alone unit.
For more information about setting the boot device for the processor, see
“Boot Mode and Clock Ratio Select Switch (SW10)” on page 2-12 .
Table 1-1 provides a map of the board’s external memory.
Table 1-1. EZ-KIT Lite Evaluation Board External Memory
Start Address End Address Content
0x0100 0000 0x010F FFFF Flash memory
0x0120 0000 0x0127 FFFF SRAM memory
0x0140 0000 0x0140 FFFF LEDs (see “LEDs and Push Buttons” on page 2-13 )
0x0160 0000 0x017F FFFF Unused chip select 1
0x0180 0000 0x019F FFFF Unused chip select 2
