Analog Audio
1-8
ADSP-21364 EZ-KIT Lite Evaluation System Manual
The parallel flash memory and the SRAM connect to the parallel port of
the processor. The parallel port is a multiplexed address and data port.
The port can connect to 8-bit and 16-bit memory devices. When config-
uring the parallel port, keep in mind that the memory devices on the
board are 8 bits wide.
To access the SRAM and flash memories, set up a parallel port DMA. For
more information on how to connect the SRAM and flash memories, see
The SPI flash memory connects to the SPI port of the processor and uses
FLAG0
as a chip select. In order for
FLAG0
to behave as a chip select, clear
the
PPFLG
bit in the
SYSCTL
register.
An example program is included in the EZ-KIT Lite installation directory
to demonstrate how the parallel port and SPI port can be configured to
access the memories.
Analog Audio
The AD1835A is a high-performance, single-chip codec featuring four ste-
reo digital-to-analog converters (DAC) for audio output and one stereo
analog-to-digital converters (ADC) for audio input. The codec can input
and output data with a sample rate of up to 96 kHz on all channels. A
192 kHz sample rate can be used with the one of the DAC channels.
The processor interfaces with the AD1835A codec via the DAI port. The
DAI interface pins can be configured to transfer serial data from the
AD1835A codec in either time-division multiplexed (TDM) or two-wire
interface (TWI) mode. For more information on how the AD1835A con-
nects to the DAI, see
.
The master input clock (
MCLK
) for the AD1835A can be generated by the
on-board 12.288 MHz oscillator or can be supplied by one of the DAI
pins of the processor. Using one of the pins to generate the
MCLK
, as
