ADSP-21364 EZ-KIT Lite Evaluation System Manual
Access to the ADSP-21364 processor from a personal computer (PC) is
achieved through a USB port or an optional JTAG emulator. The USB
interface gives unrestricted access to the ADSP-21364 processor and the
evaluation board peripherals. Analog Devices JTAG emulators offer faster
communication between the host PC and target hardware. Analog Devices
carries a wide range of in-circuit emulation products. To learn more about
Analog Devices emulators and processor development tools, go to
L
The ADSP-21364 EZ-KIT Lite installation is part of the Visu-
alDSP++ installation. The EZ-KIT Lite is a licensed product that
offers an unrestricted evaluation license for the first 90 days. For
details about evaluation license restrictions after the 90 days, refer
to
“Evaluation License Restrictions” on page 1-7
.
ADSP-21364 EZ-KIT Lite provides example programs to demonstrate the
capabilities of the evaluation board.
The board features:
• Analog Devices ADSP-21364 processor
D
136-pin BGA package
D
300 MHz core clock speed
• Synchronous random access memory (SRAM)
D
512 Kbit x 8-bit
• Flash memory
D
1M x 8-bit
• Serial peripheral interface (SPI) flash memory
D
2 Mbit
