FIGURE 2. Screen Elements
1 Page 3 Right-click Menu
2 Tab
Page
The main elements at the top of the window are Pages. Click a page to go to that page in the
software. All of the pages except the Home page, and in some cases the Admin page, can
be moved or deleted. For additional information, see the System Setup Tab section.
Tab
The elements on the left side of the window are Tabs. Click a tab to display information and
tasks on that tab. Some tabs require you to go in order, and will not let you click a tab further
down without performing a task on the current tab.
Right-click Menu
Certain sections of the software such as tables, lists, and text boxes have right-click option
menus. Menus are different depending upon the item you right-clicked.
• Print All - Prints all sections or cells of the item
• Print Selection - Prints only the selected section or cell
• Import - Imports a file
Touring the Software
9
