34
STEP 12 Programming wireless Keypad
(model 433 KPD)
Terms to understand:
Master Password – The 5-digit code used to access programming features. Factory default is “11111.” This
needs to be changed by the end user for security reasons.
Access Code – The 1 to 5-digit code used to open the gate (24 unique codes are possible). If access code is less
than 5 digits it requires the # sign after code is entered. Example: “2 #.” If the code is 5 digits the # sign is not
required.
Relay 1 – The receiver has 2 relays. P1 (relay 1) is factory wired to the “push button input” on Patriot control
board.
Relay 2 – The receiver has 2 relays. P2 (relay 2) is factory wired to the “Free exit/Open input” on Patriot
control board.
Security Code (Dip Switch Code) – The keypad does not have dipswitches. Instead, the receiver has a learn
mode which can be used to program the keypad to the receiver. The keypad can also be manually programmed
if a transmitter is being used. See “Changing Security Code” on page 35.
PUK Code – “Password Unblocking Key.” The PUK code is located inside the keypad and is needed when the
master password has been lost. Copy and store in a safe place for future reference. Must be 5 digits long – lead
with zeros.
“ * ” Key – located on the keypad is used to cancel last command entered.
Red Light Blinks – When blinking, the keypad is sending a signal to the receiver. Valid access code was
entered.
Note: Do not install keypad until “Learning Access Codes in Receiver” has been completed.
Programming New Master Password:
1 Enter the Master Password “11111.”
2 Enter “8.” If correct, 2 short beeps (if 1 long beep is heard, start over with step 1.)
3 Enter the Master Password (up to 5 digits), if less than 5 digits, “#” is required.
4 Enter “8.”
5 Enter the Master Password again to verify.
6 Press “8.” If correct, 2 short beeps the New Master Password is set. (If 1 long beep is heard, start over
with step 1.)
Programming Master Password Back to Factory Default: (11111)
1 Enter “11111.”
2 Press “8” (long beep.)
3 Enter PUK code. (PUK must be 5 digits)
4 Press “8.”
5 Enter PUK code to confirm.
6 Press “8” (2 beeps) Master password reset complete.
Programming the Keypad for Operation
Create Access Code: (Code you use to operate the gate)
1 Enter the Master Password “11111.”
2 Enter “9.” If correct, 2 short beeps (if 1 long beep is heard, start over with step 1.)
3 Enter the new Access Code (up to 5 digits), if less than 5 digits, “#” is required.
4 Enter “9.”
5 Enter the new Access Code again to verify.
6 Enter “1” or “2” representing the relay (relay 1 or 2 in the receiver) you want to control.
If correct, 2 short beeps (if 1 long beep is heard, start over with step.
