Web Managed GbE Switch
43
Click Switching->SVLAN->SVLAN Service Port to access the screen below.
The following table describes the labels on this screen.
LABEL
DESCRIPTION
Port
Select the port(s) to configure the settings for.
Enabled
Set VLAN stacking aware state:
Enabled: Set as VLAN stacking aware.
Disabled: Set as VLAN stacking unaware.
Apply
Click Apply to save your changes to the switch.
3.3.6 Bandwidth Control
3.3.6.1 Preamble Setting
Click Switching > Bandwidth Control->Preamble Setting in the navigation panel to bring up the
screen shown below.
