Specifications
General
DSP Measurement Technique
Transit time
Flow Velocity Range 0.1 m/s - 10 m/s; bi-directional
Accuracy ±3 % of flow reading for flow rate >0.3 m/s
Repeatability ±0.5 % of measured value
Response Time
<
500 ms
Selectable Flow Units Velocity m/s, ft/s
Volume l/s, l/min, gal/s, gal/min, USgal/s, USgal/min, m 3 /min, m 3 /h
Selectable Total Volume Units liters, m 3 , gallons, US gallons
Menu Languages EN
Environmental
Operating Temperature
0 °C to 50 °C -32 °F to 122 °F
Storage Temperature -10 °C to 60 °C -14 °F to 140 °F
Pipe Wall Temperature 0 °C to 85 °C -32 °F to 185 °F
Operating Humidity Max. 90% relative humidity @ 50 °C (122 °F)
Applicable Pipe Types
Pipe Materials
PVDF-SYGEF, PP-PROGEF, PE-ELGEF, PB-INSTAFLEX, ABS, PVC-U/PVC-C, Mild Steel,
Ductile Iron, Stainless Steel 316
Pipe Dimension (OD) 25 - 115 mm 1 - 4.5 inch
Electrical
Supply Voltage
12 to 24 V AC or DC
Power Consumption Max. 7 VA
Outputs
Analog Output Range
4 to 20 mA
Resolution 0.1 % of full scale
Load max. 620 Ω
Isolation 1500 V Opto-isolated
Alarm Current 3.5 mA
Pulse Output Type Digital MOSFET relay, voltage free NO contact
Pulse Repetition 1 - 166 pps user programmable, Frequency mode max. 200 Hz
Pulse width 25 ms default value, 3 - 99 ms user programmable
Voltage max. 48 V AC
Current max. 500 mA
Isolation 2500 V opto isolated
Enclosure and Display
Material
Polycarbonate
Dimensions 250 x 48 x 90 mm 9.85 x 1.9 x 3.55 inch
Weight 0.5 kg 1.1 lb
Keypad 4 key tactile feedback membrane keypad
Display Type 2 line x 16 characters
Viewing Angle Min. 30°, Max. 40°
Active Area 83 x 18.6 mm 3.3 x 0.73 inch
IP Rating IP 54
Shipping Information
Box Dimensions
290 x 280 x 100 mm 11.4 x 11 x 4 inch
Weight 1.4 kg 0.05 lb
Volumetric Weight 1.4 kg 0.05 lb
Standards and Approvals
CE, RoHS compliant
Safety
BS EN 61010-1:2001
EMC BS EN 61326-1:2006 BS EN 61326-2-3:2006
Environmental BS EN 60068-1:1995
BS EN 60068-2-1:2007 BS EN 60068-2-2:2007
