11.5.2 Wiring

diagram

11.5.2.1 Wiring diagram for the integral mount configuration of sensor and CT

Supply and end connections

of the CT transmitter

17 + Binary output 1

47 + Binary output 1

17 + Binary output 1

16 -

(pulse/frequency)

46 -

(pulse/frequency)

16 -

(pulse/frequency)

16 -

(pulse/frequency)

20 + Binary output 2

50 + Binary output 2

20 + Binary output 2

19 -

(status output)

49 -

(pulse/frequency)

19 -

(pulse/frequency)

19 -

(pulse/frequency)

14 + Current output 2

44 + Current output 2

34 + Binary output 3

36 B RS485

13 -

(0/4-20 mA)

43 -

(0/4-20 mA)

33 -

(status output)

35 A

(Modbus)

12 + Current output 1

42 + Current output 1

12 + Current output 1

11 -

(0/4-20 mA HART®)

41 -

(0/4-20 mA HART®)

11 -

(0/4-20 mA HART®)

11 -

(0/4-20 mA)

Modbus (planned)

(RS485 - IS)

Process outputs wiring

Standard EEx ia /

Not Ex

Standard EEx e

Custody transfer

Note: RS 485 not currently available
