35
Adjustment and commissioning
Type 8025 UNIVERSAL
8 ADjUSTmENT AND
commISSIoNING
8.1 Safety instructions
Warning
risk of injury due to nonconforming operating.
Nonconforming▶operating▶could▶lead▶to▶injuries▶and▶damage▶the▶
device▶and▶its▶surroundings.
▶ ▶ The▶operators▶in▶charge▶of▶operating▶must▶have▶read▶and▶under-
stood▶the▶contents▶of▶this▶manual.
▶ ▶ In▶particular,▶observe▶the▶safety▶recommendations▶and▶intended▶use.
▶ ▶ The▶device/installation▶must▶only▶be▶operated▶by▶suitably▶trained▶
staff.
Warning
danger due to nonconforming commissioning.
Nonconforming▶commissioning▶could▶lead▶to▶injuries▶and▶damage▶
the▶device▶and▶its▶surroundings.▶
▶ ▶ Before▶commissioning,▶make▶sure▶that▶the▶staff▶in▶charge▶have▶read▶
and▶fully▶understood▶the▶contents▶of▶the▶operating▶instructions.
▶ ▶ In▶particular,▶observe▶the▶safety▶recommendations▶and▶intended▶use.
▶ ▶ The▶device▶/▶the▶installation▶must▶only▶be▶commissioned▶by▶suit-
ably▶trained▶staff.
▶ ▶ Before▶commissioning▶the▶device,▶enter▶the▶K▶factor▶of▶the▶fitting▶
used.▶See▶chap.▶„8.7▶Entering▶the▶K▶factor▶of▶the▶fitting▶used“.
8.2 operating levels of the device
The▶device▶has▶two▶operating▶levels:▶the▶Process▶level▶and▶the▶Con-
figuration▶level.
Tab. 3: Default settings of the device
Function Default▶value
LANGUAGE English
UNIT▶of▶the▶flow▶rate l/min.
UNIT▶of▶the▶totalizers litre
OUTPUT▶AO1 4mA=▶0.000
20mA=▶0.000
ERR.▶22mA▶disabled
OUTPUT▶DO1 pulse
PU=▶0.00▶litre
OUTPUTS▶DO2▶and▶
DO3 Hysteresis,▶not▶inverted
2-▶=▶3-▶=▶0.000
2+▶=▶3+▶=▶0.000
time▶delays▶2▶and▶3▶=▶0
K▶FACTOR 1
FILTER 2,▶fast
CUT-OFF 0.000
BACKLIGHT level▶9,▶activated▶for▶30s
FLOW-WARNING W-▶=▶W+▶=▶0.000
VOLUME-WARNING 000000
