Brooks
®
GF40/GF80/GF81 Devices
Installation and Operation Manual
X-TMF-GF40-GF80-Series-MFC-eng
Part Number: 541B161AAG
June, 2013
Section 1 Introduction
Figure 1-4 Dimensions - GF81 Series, RS485/Analog & Profibus
Model GF81 Profibus
Model GF81 RS485/Analog
3.67
93.1
5.71
145.1
5.84
148.3
.50
12.7
3.43
87.1
.50
12.7
5.28
134.2
1.48
37.6
1.13
28.6
1.17
29.7
1.13
28.7
1.13
28.7
.58
14.8
.58
14.8
