3-1
Brooks ® Models 5964, 5850EM
Section 3 Operation Installation and Operation Manual
X-TMF-5964-5850EM-MFC-eng
Part Number: 541B121AHG
November, 2008
3-1 Overview
After the flowmeter has been properly installed in the process, it is ready
for operation. When initiating flow, slowly open the valve to avoid a flow
surge.Bypass is a help in bringing the flow on smoothly. Avoid starting a
pump to supply the flowmeter without the use of a valve upstream of the
flowmeter.
This section contains the following information:
• Features and Jumper Configurations
• Theory of Operation
• Adjustment Potentiometers
• Calibration and Response Adjustments
3-2 Connections and Controls
Figure 3-1 shows the locations of the Model 5964/5850EM controls and
connections. Figure 3-2 identifies the externally accessible adjustment
potentiometers located on the inlet side of the instrument.
