Creating Presets
The SMX200 allows the creation of user defined presets very easily. Any setup you have configured on
screen, can be stored into one of the 8 available user presets.
1. After having configured Layers, PIP transitions, logos... on your screen (see Working with the SMX200,
p.31), go to the Preset menu by pressing the EXIT/MENU button, and select Preset by rotating the scroll
knob. Then, press the ENTER button to enter the Preset sub-menu. Choose Preset Copy by scrolling with
the corresponding knob, and press the ENTER button to access the sub-menu.
2. In the sub-menu, choose Save From Main or Save From Preview to determine which screen you want to
memorize the preset from, then set the preset memory (#1 to #8) you wish to use as your “User Preset”
(by default, the SMX200 will choose the next available preset in the SMX200 memory).
3. By pressing the ENTER button, the SMX200 will ask you to confirm. Select Yes, your screen is memorized
as a preset.
Logos as Layer
Working with Presets
The four user presets of the SMX200 can be called back at any stage during your show or event.
1. Press the PRESET button, then press one of the four first Input Selection section buttons to choose which
memory (#1 to #4) you wish to use. The preset will be displayed on your preview screen.
2. Once you have selected your preset, simply press the TAKE button to view the result on your main screen.
Logos are under the Layer rules, you will have access to settings directly by pressing the Logo Layer button.
You have 2 Layers Logo button available.
You can use the Pos/Size/Zoom adjustment button and the Effect button from the front panel too.
Working with Logos
A simple or animated Logo can be manipulated thanks to the front panel. On the front panel, the logo# are
associated to the input# respectively. To affect a logo# to the logo layer:
Press Logo1 Layer button → Press Input#
Logos #1 to #6 are available directly by the input # button on the front panel. For logo #7 and #8, you have to
use the Shift button first:
Press Logo1 Layer button → Press Shift button → Press Input#
(for logo #7 or #8 use Shift then Input# button)
You can change logos or delete logos on the preview screen using the same way the layers do:
Delete: Press Logo (#1 or #2) button → Press Black
Change: Press Logo (#1 or #2) button → Press another Input#
Working with Audio
The SMX200 allows to work with up to 10 stereo inputs, 1 auxiliary input, and 2 embedded SDI audio inputs
(via the SDI BNC connectors), all accessible via the Audio menu of the SMX200, and which can be affected
to one or both of the 2 independant symetrical/asymetrical outputs of the device.
45
