Working with Cut, Fade or Transitions

All the transitions (Cut, Fade or Transistions) are available in the native Matrix Mode. Although the Matrix

Mode is activated, you will be able to perform powerful transition effects seamlessly. It can depend on your

configuration.

The

Smart MatriX has 4 scalers, to understand how your effect will be performed, you need to know how

many scalers are used on your outputs. Don’t forget that you always need one free scaler to perform clean

transition. Example:

1 background live on each output → 2 scalers used →

2 seamless transitions

1 background line on each output + 1 PIP on output #1 → 3 scalers used →

1 seamless

transition available only on output #2 but the output #1 with a background live + 1 PIP

will not be seamless transition

(ie: Fade through black)

1 background frame on each output + 2 PIP on each outputs → 4 scalers used →

seamless transition

(ie: fade through black)

The background Frame and the Logos are not considerated as live layers and are not counted as using a

scaler.

Working with Layers Functions

Once a source attached to a layer, you will have access to some layer settings in the Layer menu or directly

by pressing the layer button.

The settings available depend on the layer selected:

Layer adjusts:

set up layer size and position.

Layer zoom:

set up layer zoom size and position.

- Transparency:

adjust the Layer transparency.

- Border:

choose the border and adjust its properties.

Opening and Closing effect:

adjust the Open/Close effect type and duration.

Smooth move:

enable/disable smooth move.

Status:

get the selected layer status.

*All changes have to be validated by pressing the OK button in order to be saved*

Press Take to view the result on the main screen.

Settings available:

Settings

Background Live / PIP#1

PIP#2

PIP#3

Position

YES

Size

YES

Zoom

YES

Transparency

YES

Border

YES

Opening effects

YES

Closing effects

YES

Smooth Move

YES

H Flip / V Flip

YES
