OPERATING THE SMART MATRIX
4-1. THE SMART MATRIX FRONT PANEL
Overview
The highly intuitive front panel of the
Smart MatriX was designed by Analog Way engineers to simply and
quickly meet all of your event needs. Within minutes, you will be able to enjoy its full potential and easily
parameter most of its functions, without having to be an expert audio-visual engineer, leaving room for what
is most important to our users: concentrating on their event.
The
Smart MatriX front panel is comprised of several sections, each carefully labelled and self explanatory,
corresponding to all the machine’s versatile functions.
1 : Standby button
2 : Menu screen
3 : Menu scroll knob
4 : Control section
