OperatiOnal DimensiOns

1.25 (31.8)

0.62 (16.0)

2.0 (50.8) Typ

Ш 0.4 (10.2)

Ш 0.5 (12.7)

2.63 (66.8) Radius

2.0

(50.8)

Typ

3.65

(92.7)

Typ

4.9

(124.5)

Typ

Spherical bearing mount assembly

NOTE: Dimensions typical for both arms

Dimensions in Inch (mm)

Sample boring bar broached hole locations (72 inch (1828.8 mm) bar only)

14.0 (355.6)

12.0 (304.8)

40.0 (1016.0)

71.75 (1822.5)

0.5 (12.7)

First hole is 1 inch (25.4 mm) from the

end of the bar.

Holes in this example are spaced 10 inches (254.0mm) apart. Other hole spacing is available.



Portable Machine Tools, Inc. ©

Newberg, OR USA 97132

WWW.CPMT.COM inside U.S. 1-800-333-8311

36961

ASSY MOUNT UNIVERSAL 1-1/4 BAR BB3000 W/BRNG












