84

Capacitance

When measuring capacitors, it is always most

desirable if the dissipation factor is low. Electrolytic

capacitors inherently have a higher dissipation factor

due to their normally high internal leakage

characteristics. In some cases, if the D (dissipation

factor) is excessive, measurement accuracy may

degrade and even read out of specification.

Inductance

Some inductors are intended to operate at a certain

DC bias to achieve a certain inductance value.

However, the 878B and 879B LCR meters cannot

produce such biasing scheme and external biasing

should not be attempted because external power

would be applied to the instrument and cause serious

damage to the meter. Therefore, in some cases,

measured inductance reading may not agree with

manufacturer’s specification. It is important to check if

specification pertains to DC biasing or not.

Resistance

When measuring resistance of devices, it is important

to know that there are two types or ways of

measurement. One type is DC resistance

measurement. Another type is AC resistance

measurement. The 879B and 878B uses AC

resistance measurement method and does not
