34

Setup Tolerance

1. Select the primary measurement mode based

on the type of components to be measured.

This is done by pressing the

(or

for model 878B) button to configure the

desired measurement mode.

Note: Be sure to select the correct

measurement mode, as tolerance mode

cannot be activated unless the correct mode

is selected. For example, if the component is

a capacitor, be sure to select “C” for

capacitance. If not, tolerance mode will not

be activated following the proceeding steps

below.

2. Insert the component to be used as the

“standard” reference value. Another words,

insert a known “good” component that will be

used for testing against all other components.

(See Figure 6 for illustration)

Note: The tolerance mode cannot be

activated unless the meter senses a

component is connected to either the input

sockets or terminals.
