7
Switching speed 1, 2
Type Standard Option UNZ Option UNZ
typical
Digital modulation off
SCPI mode ≤ 5 ms (typ) ≤ 750 µs ≤ 650 µs
List/Step sweep mode ≤ 5 ms (typ) ≤ 500 µs ≤ 400 µs
Digital modulation on
SCPI mode ≤ 5 ms (typ) ≤ 1.15 ms ≤ 950 µs
List/Step sweep mode ≤ 5 ms (typ) ≤ 900 µs ≤ 700 µs
Absolute level accuracy in CW mode 3
[ALC on]
Standard Option 1EQ
+23 5 to –60 dBm < –60 to –110 dBm < –110 to –127 dBm
100 kHz to 250 kHz 4 ±0.6 dB ±1.0 dB —
> 250 kHz to 1 MHz ±0.6 dB ±0.7 dB ±1.7 dB
> 1 MHz to 1 GHz ±0.6 dB ±0.7 dB ±1.0 dB
> 1 to 3 GHz ±0.6 dB ±0.8 dB ±1.1 dB
> 3 to 4 GHz ±0.7 dB ±0.8 dB ±1.1 dB
> 4 to 6 GHz ±0.8 dB ±1.1 dB ±1.3 dB
1. Time from receipt of SCPI command or trigger signal to amplitude settled within 0.2 dB. For
units with serial numbers ending in 4742xxxx or less, switching speed is specified for power
levels < +5 dBm.
2. Switching speed specifications apply when status register updates are off.
3. Quoted specifications between 20 °C and 30 °C. For temperatures outside this range, abso-
lute level accuracy degrades by 0.005 dB/°C for frequencies ≤ 4.5 GHz and 0.01 dB/°C for
frequencies > 4.5 GHz. Output power may drift up to .003 dB per g/Kg change in specific
humidity (nom).
4. Specification applies to units with serial numbers ending with 4818xxxx or greater.
5. For units with lower serial numbers refer to the Archive Section at end of this document, or
maximum specified output power, whichever is lower.
