Parts of the analyzer, Figure 1. front, back, and top panels, Front – Alpha Technologies Celltron Essential CTE-1200 AT; CTE-2200 AT; CTE-3200 AT User Manual
Page 9: Back, Infrared light screw holes cable port fuse holder, Screen, Up down enter retest menu, Battery door
3
Parts of the analyzer
Panels
The panels allow you to use, care for, and hook up the analyzer. Figure 1 displays the front, back, and
top panels of the analyzer and their parts.
Top
Infrared light
Screw holes
Cable port
Fuse holder
Figure 1. Front, back, and top panels
