 30 
4. Press  or  to scroll to
PRINT RESULTS and press ENTER .
4. PRINT RESULTS
5. VIEW RESULTS
6. EXPORT DATA
MENU
Printing will begin after selecting a site. Printing will begin after selecting a site.
PRINT RESULTS

IN PROGRESS
5. The printout displays the following values for each
jar post or strap:
• Voltage
• Percentage of the reference value
• Conductance value
• Temperature
• Volts per jar
The printout also displays setup information and
string summary. See Figure 9.
For more information about the printer, refer to
the printer User Guide.
Downloading Test Results
To download test results to your PC, aim the infrared light
on top of the analyzer towared the infrared receiver attached
to your computer, and choose option
6. EXPORT DATA
from
the main MENU.
Note: Refer to your Battery Management Software manual
for instructions on how to install the infrared receiver to
your computer.
Figure 9. Sample of a printout
CELLTRON ESSENTIAL
NOTES: _________________
________________________
________________________
STRING NAME:
02. SITE 02
BATTERY MANUFACTURER:
ALPHACELL
BATTERY MODEL:
160AGM
TEST DATE:
04/08/05 2:12 PM
REFERENCE VALUE ENTERED:
1300 SIEMENS (MHOS)
REFERENCE TEMPERATURE:
25 DEGREES CELSIUS
----STRING STATISTICS---
STRING AVERAGE: 1404s
STRING% OF REF: 108%
STRING% OF HI JAR: 91%
-----JAR STATISTICS-----
JAR VOLTS MHOS %REF
01A 6.669 1432 110%
02A 6.766 1499 115%
03A 6.754 1542 119%
04A 6.738 1536 118%
05A 6.724 1527 117%
06A 6.715 1511 116%
01B 6.703 1535 118%
02B 6.692 1512 116%
03B 6.681 1512 116%
04B 6.669 1520 117%
05B 6.664 793? 61%
06B 6.657 1532 118%
01C 6.652 803? 62%
LOWEST JAR:
J05B 61%
HIGHEST JAR:
J03A 119%
---SETUP INFORMATION---
STRING WARN % (?): 70%
STRING FAIL % (!): 60%
JAR WARN % (?): 70%
JAR FAIL % (!): 60%
VOLTS/JAR SELECTED: 6V
SYSTEM VOLTS: 36V
END OF DATA
