 6 
2. TEST BATTERY option
The
TEST BATTERY option allows you to test a jar after you connect the cables to the jar posts. If you
do not have the cables connected to the jar posts before you select TEST BATTERY , the screen prompts
you to connect to a jar.
3. VIEW PARAMETERS menu
The
VIEW PARAMETERS menu displays the values you set up for a site under the SET PARAMETERS
menu. This menu allows you to view the parameters only. For descriptions of these options, refer to
“ SET PARAMETERS menu.”
4. PRINT RESULTS option
The
PRINT RESULTS option allows you to print test results for a site you tested.
5. VIEW RESULTS menu
The
VIEW RESULTS
option allows you to view test results
for a site you tested. When you select the site, the screen
displays the following options, described in Table 3:
Table 3. VIEW RESULTS menu options
Option Description
SITE
SUMMARY
Lists these values as a summary of the site you tested:
• AVG. % — Average percentage of the reference value.
• AVG. SIEMENS: — Average conductance value.
• TOTAL JARS: — Total number of jars you tested in the site.
• LOW: — Jar number with the lowest percentage of the reference value.
• HIGH: — Jar number with the highest percentage of the reference value.
• SITE — Average percentage of the site’s strings as compared to the jar in
the site with the highest conductance value.
REVIEW DATA
SET
Gives the following information for each Jar and Strap test:
• voltage
• conductance value
• number of the jar or strap
• percent of the reference value
• warning and failure indicators
The analyzer keeps the test results for a site until you erase the data.
Helpful hint:
The
RETEST button provides a shortcut to the REVIEW DATA SET screen.
1. SITE SUMMARY
2. REVIEW DATA SET
3. MAIN MENU
03. SITE 03
