 4 
Parts on the panels
Table 1 describes the parts of the panels.
Table 1. Parts of the panels
Part Description
Screen Displays menus, options, and test results.
UP Enables you to scroll up in a menu or number selections.
DOWN Enables you to scroll down in a menu or number selections.
ENTER Moves to the option you select or enters number selections.
RETEST Opens a menu with options to retest the jar or strap you just tested.
MENU Turns the analyzer on and off.
Battery door Covers the analyzer battery compartment.
Infrared light Transfers data from the analyzer to the printer, or to another IR receiver.
Screw holes Enables screws to anchor the cable to the analyzer.
Cable port Connects the probes or clamps to the analyzer.
Fuse holder Houses the fuse for the analyzer.
Menu options
Menus
The analyzer displays menus on the screen from which you can select options before, during, and
after testing. You can access options from the main MENU .
Main MENU
To access the main
MENU , press and hold the MENU
button. The main
MENU displays these options:
1. SET PARAMETERS
2. TEST BATTERY
3. VIEW PARAMETERS
4. PRINT RESULTS
5. VIEW RESULTS
6. EXPORT DATA
7. CHANGE REF.
8. UTILITIES
NOTE: If the analyzer was last used while
in UTILITIES mode, that will be the first
menu displayed when you turn the unit
back on. To return to the main
MENU
,
scroll to I. MAIN MENU and press ENTER .
