 5 
Note: All main MENU choices (except UTILITIES )
lead to a list of sites, from 01. to 12.
Option 13. ALL SITES (available for 1, 4, 6 and 7 only--
SET PARAMETERS, PRINT, EXPORT, or CHANGE REF )
allows you to apply the option to all 12 sites.
1. SET PARAMETERS menu
The
SET PARAMETERS menu allows you to set values for a site so it is ready to test. If you do not, the
analyzer tests the string against the last setting used.
The screen displays these options, along with their currently specified values, as described in Table 2:
1. SYSTEM VOLTS 36V
2. JARS ONLY
3. TEMP
25°C
4. REF 1000 S
5. VOLTS/JAR 12
6. SELECT BATTERY
7. MAIN MENU
Table 2. SET PARAMETERS menu options
Option Description
SYSTEM VOLTAGE The nominal number of volts in the system (36 or 48V). The default is 36 V.
JARS ONLY, or
JARS & STRAPS
• Jars (JARS ONLY)
• Cells and inter-cell connections of the site (JARS & STRAPS)
The default is JARS ONLY.
TEMP
Temperature of the site. The analyzer compensates for temperature since
conductance measurements change with jar temperature. The analyzer
measures an absolute conductance value. However, it uses the TEMP
value to adjust the reference value you enter in REF. The percent is
compensated to 25 °C (77 °F). Compensation is adjusted at 0.7% per
degree Celsius between 0 °C and 35 °C.
The default is 25 °C (77 °F).
REF
Reference value in siemens. For more information about reference values,
refer to “Determining a reference value.” The default is 1000 S.
VOLTS/JAR Number of volts for a battery (6 or 12 V). The default is 12 V.
SELECT BATTERY Choose the battery you wish to test.
MAIN MENU Returns to the top menu.
A full description and instructions for the SET PARAMETERS menu is provided in “Chapter 2.
Setting Parameters.”
01. SITE 01
02. SITE 02
03. SITE 03
SELECT SITE
