Screen if the analyzer is in MANUAL START :
READY TO TEST
SITE 01 J01A
START TEST
BATTERY TEST
3. If you selected MANUAL START when you set values in the UTILITIES menu, press ENTER
to start testing.

--SELF CALIBRATING--
BATTERY TEST

--AUTO RANGING--
BATTERY TEST
The analyzer beeps twice when the test is done. If test results are under the values you set in the SET
PARAMETERS and UTILITIES menus, the analyzer also beeps longer for each of the following:
• Conductance value is below the reference value, and the percentage of
the reference is below the values for WARN or FAIL
• The voltage is below the LOW VOLTS value
• The voltage is above 2.5 volts per cell
• Four strings have been tested
4. Choose one of the following based on the type of testing you are doing:
• If you are testing jars only, test the next set of jar posts if you have more
than one set of posts or test the next jar in the string. Refer to the test
patterns in “Determining a test pattern.”
• If you are testing jars and straps, follow the steps in “Attaching the cable
to a strap.”
Attaching the cable to a strap
To attach the cable to a strap:
1. Remove the red probe or clamp from the red (+) terminal.
2. Attach the red probe or clamp at the end of the strap above the black (–) terminal
on the next jar. Refer to Figure 6.
3. Test the jar connected to the jar you just tested. Follow the steps in est the jar connected to the jar you just tested. Follow the steps in “Attaching
the cable to jar posts.”
4. Repeat the steps in “Attaching the cable to jar posts” and “Attaching the cable
to a strap” until you are finished testing all the strings in the site.
5. Refer to “Chapter 4: Test Results” to view test results or “Retesting jar posts
or straps” to retest the set of jar posts or straps.
