The enclosure is equipped with a Square D, rainproof load center box (SUSE rated). The service entrance is
equipped for a 120/240VAC, split phase, -wire with ground source.
If the wire at L2 is black, place red tape (or label) on it.
6. Connect the #6AWG White wire to the neutral (N) bus lug located to the top right of
the circuit breaker assembly.
7. Connect the #2AWG stranded copper ground wire (Earth Ground) to the ground and
neutral bus located to the right side of the circuit breaker assembly.
8. Notify the electrical inspector to approve the service entrance wiring. Once approved,
contact the local power utility for electrical service.
Connection Procedure:
1. Locate the service entrance panel on the enclosure. Remove the cover to access
the circuit breaker assembly. If this service panel is to be used as the primary service
entrance, neutral must be bonded to ground by installing the green ground screw
(provided) in the hole in the neutral bus.
2. Remove the knockout located in the service entrance to accept the conduit.
. Install the conduit nipple into the service entrance via the knockout and secure it using
the appropriate threaded conduit locknut.
4. Locate the two screw terminals (L1 and L2) on the service circuit breaker.
5. Connect one of the incoming Black #6AWG wires to L1 (left terminal). Connect the
remaining Black (or Red) #6AWG wire to L2 (right terminal).
5.0 Installation, continued
5.4 Connecting to Utility Power
Verify electrical codes prior to installation. Codes may vary and contain specific conduit and wire sizes for
connection to the load center. Connection to utility power must be approved by the local utility before installing
the power supply.
ATTENTION:
NOTE:
NOTE:
