MiniBay configured with the following options:
Side Chamber (designed to NEMA 4X specifications)
60A Internal AC Service (Square D QO Series)
EUSERC Meter Base (240VAC with Test Bypass Blocks)
Fusible Service Entrance Disconnect (100,000 AIC rating)
Side Chamber Door Viewing Window
TVSS (Transient Voltage Surge Suppression) Module
Cable Entry Seals
Master Ground Bar
Telcom -point Door Latch
Door Activated Light and Tamper Switch
Also shown on this unit:
,000 BTU DC Air Conditioner
Battery Storage Unit
Pin Allen Telecom Locks
Fig. 1-, Interior View of the MiniBay Side Chamber
Viewing Window
Meter Base
Fused Disconnect
Ground Bar
EUSERC
Meter Base
AC Distribution
Breaker Panel
Door-activated
Tamper Switch
and Light.
Pin Allen -point
Door Latch
Cable Entry Port Seals
