46 044-001-C0-00, Rev. C
Fig. 4-10, Typical Site Arrangement, (stand-alone cabinet)
4.0 Site Preparation, continued
4.4
Site Configuration, continued
Figure 4-10 (below) shows the cable conduit route into the back of the enclosure.
Verify the conduit is trimmed 1" to 2" above the pad surface (for side chamber), or 1" to 4" for riser.
NOTE:
PRE-CAST PAD
E
B
A
D
B
A
C
C
D
E
Back
Front
Precast Polymer Pad
Compacted Gravel (12" depth recommended
Level Grade
Area of Backfilled Soil
Trench for Sweep (sweep enters back of cabinet)
