1.0 Overview and Specifications, continued
1.2 Enclosure Specifications
Equipment Enclosure Weight: 195 lbs (88.5kg)
Dimensions (in/mm):
44H x 30W x 32D (1067 x 762 x 813)
Material: High Strength Corrosion Resistant
Aluminum
Finish: Almond Color Powdercoat Finish
19" or 23" wide Fixed Relay Rack
tapped or with Tinnerman nuts
19" Swing Rack (tapped only)
Battery Storage Unit Weight (without batteries): 130 lbs (59kg)
Dimensions (in/mm):
14.0H x 30W x 32D (356 x 762 x 813)
Slide Tray, Alpha P/N 0-08-20,
will hold four GNB M12V155FT batteries
Fixed Tray, Alpha P/N 0-08-2,
will hold three Avestor batteries.
Riser Module
14" Riser Alpha P/N 033-083-21
7" Skirt/Riser Alpha P/N 033-084-20
7" C-channel Riser Alpha P/N 745-650-20
Weight: 102 lbs (46.3kg)
Dimensions (in/mm):
14H x 30W x 32D (356 x 762 x 813)
Side Chamber SC1 Weight: 100 lbs (45.4kg)
Dimensions (in/mm):
72H x 32W x12D (813 x 1829 x 305)
Side Chamber SC2 Weight: 89 lbs (40.4kg)
Dimensions (in/mm):
58H x 32W x 12D (813 x 1321 x 305)
1.3 MiniBay Accessories
Precast Polymer Concrete Padfor Single Radium MiniBay P/N 641-110-10
Precast Polymer Concrete Pad for Single Radium MiniBay + Side
Chamber
P/N 641-114-10
Pour-in-place Pad Template P/N 604-09-N1
Pour-in-place Pad Template Tie-bars (spacers for 2 template kits) P/N 745-2-20
Pour-in-place Side Chamber Template P/N 745--20
Vapor Barrier for MiniBay (die cut template matches MiniBay) P/N 564-990-10
SRG PROT, 5-pin, Gas Tube, B1E P/N 162-016-10
Touch-up Spray Paint, Almond P/N 972-056-10
Pad Mounting Hardware Kit (4 Hilti KBII sleeve anchors 1/2 x 3-3/4) P/N 745-592-21
Pad Mounting Hardware (4 Hilti HSLG M12/0 *60 heavy duty sleeve
anchors) requires 12mm metric drill Kit for Zone 4
P/N 745-592-20
