48 044-001-C0-00, Rev. C
5.0 Installation
This section describes the procedures for installing the enclosure and preparing it for turn-up and test.
The procedures are comprised of the following steps:
• Cabinet installation
• Battery installation and connection
• Utility power connection
Before installation verify the following:
• All necessary grounding rods and materials are in place.
• Utility power is onsite in accordance with NEC (National Electric Code).
• Review and comply with all local safety practices for working with high-voltage systems.
• All necessary permits and permissions are granted.
• The lifting/transport path is free of obstructions.
To perform the installation procedures, the installer(s) needs to have the following tools and materials
on hand:
• Crane to lift enclosure from shipping pallet and place on pedestal
• Key to enclosure doors (P/N 964-022-10 — Pin Allen type)
• Digital RMS voltmeter
• Torque wrench with insulated handle and 7/16" socket
• 7/16" box-end wrench
• NO-OX or other suitable corrosion inhibiting agent
• Battery Cabling Kit
• Silicone sealant (GE RTV123)
The enclosure MUST be loosed from the pallet BEFORE lifting the enclosure from the truck and
placing it on the pad. Problems such as broken welds, corrosion, etc., resulting from improper
installation are not covered under warranty.
CAUTION!
