N-x144_iom_24 – Cla-Val X144 Technical Manual User Manual
Page 24

SECTION 5: Specifications (continued)
3.43
”
0.04
”
6.5-inches
4.76
”
0.04
”
Insertion Tools: Overall Length
• T1 = 6-1/2”
• T2 = 14-1/2”
Figure 5-2: X144 Insertion Tool - T1
7.63
”
0.04
”
14.5-inches
12.45
”
0.04
”
A
A
X144
Size
2"
2-1/2"
3"
4"
6"
8"
10"
12"
16"
Tool
T1
T1
T1
T1
T1
T2
T2
T2
T2
Figure 5-3: X144 Insertion Tool - T2
21
Table 5: X144 Insertion Tools
