Section 2: Installation of the X144 e-FlowMeter (continued)

2.3 - Mounting the X144 e-FlowMeter

Mount the X144 e-FlowMeter in a proper orientation as shown in Figure 2-2.

NOTE:

The X144 e-FlowMeter may be installed in inlet tap of either side of the

Cla-Val Automatic Control Valve.

CAUTION:

Failure to install the unit correctly could result in faulty operation and/or damage

to the unit.

Figure 2-2: X144 e-FlowMeter correctly installed in a Cla-Val Control Valve
