Serial Communication, cont’d

USP 405 • Serial Communication

3-4

Command/response table for SIS commands

Command

ASCII Command Response

Additional description

(host to USP)

(USP to host)

Input selection

Select video

X1

!

In

X1

All

Video input

X1

.

Example:

2!

In 02All

Select input 2 video.

Select video only

X1

&

In

X1

Vid

Video input

X1

.

Input 2 video type

Set video type, input 2 only

X8

\

Typ

X8

Specify input 2 video type.

Example:

3 \

Typ 3

Specify input 2 type as YUVp.

View video type

\

X8

Input 2 video type is

X8

.

Memory preset

Recall input configuration preset

X19

.

Rpr

X19

Recall input preset

X19

.

Save input configuration preset

X19

,

Spr

X19

Save to input preset

X19

.

Color

Set a specific color value

X3

C

Col

X3

Specify a color adjustment level.

Example:

47C

Col047

Set the color adjustment to 47.

Increment

+C

Col

X3

Increase color adjustment level.

Decrement

-C

Col

X3

Decrease color adjustment level.

View the color value

C

X3

Show the color adjustment.

Tint

Set a specific tint value

X4

T

Tin

X4

Specify a tint adjustment level.

Example:

176T

Tin176

Set the tint to 176.

Increment

+T

Tin

X4

Increase tint adjustment level.

Decrement

-T

Tin

X4

Decrease tint adjustment level.

View the tint value

T

X4

Show the tint adjustment.

Contrast

Set a specific contrast value

X4

^

Con

X4

Specify the contrast adjustment.

Increment

+^

Con

X4

Increase the contrast.

Decrement

-^

Con

X4

Decrease the contrast.

View the contrast value

^

X4

Show the contrast setting.

Brightness

Set a specific value

X2

Y

Brt

X2

Specify the brightness
adjustment.

Increment

+Y

Brt

X2

Increase the brightness.

Decrement

-Y

Brt

X2

Decrease the brightness.

View the brightness value

Y

X2

Show the brightness setting.

Zoom mode

Zoom in

+{

Zom

Zoom in.

Zoom out

-{

Zom

Zoom out.

Horizontal centering

Increment

+H

Hph

Shift right.

Decrement

-H

Hph

Shift left.

Vertical centering

Increment up

+/

Vph

Shift up.

Increment down

-/

Vph

Shift down.
