Command

ASCII Command

(Host to Scaler)

Response

(Scaler to Host)

Additional Description

Picture Adjustments (continued)

Contrast

Set a specific value

E

X1%

CONT

}

Cont 1 *

X1%

]

Set the range of image light
and dark values (contrast level)
to

X1%

for the input.

Increment contrast value

E

+ CONT

}

Cont 1 *

X1%

]

Increase the contrast level by 1.

Decrement value

E

- CONT

}

Cont 1 *

X1%

]

Decrease the contrast level by
1.

View

E

CONT

}

X1%

]

In verbose modes 2 and 3:

Cont 1 *

X1%

]

View the current contrast level
for the input.

Brightness

Set a specific value

E

X1%

BRIT

}

Brit 1 *

X1%

]

Set the intensity of video light
on the screen (brightness level)
to

X1%

for the input.

Increment value

E

+ BRIT

}

Brit 1 *

X1%

]

Increase the brightness level
by 1.

Decrement value

E

- BRIT

}

Brit 1 *

X1%

]

Decrease the brightness level
by 1.

View

E

BRIT

}

X1%

]

In verbose modes 2 and 3:

Brit 1 *

X1%

]

View the current brightness
level for the input.

Detail Filter

Set detail level

E

X1%

HDET }

Hdet 1 *

X1%

]

Set the sharpness (detail) level
to

X1%

for the input.

Increment value

E

+ HDET }

Hdet 1 *

X1%

]

Increase the detail level by 1.

Decrement value

E

- HDET }

Hdet 1 *

X1%

]

Decrease the detail level by 1.

View detail value

E

HDET }

X1%

]

In verbose modes 2 and 3:

Hdet 1 *

X1%

]

Show the detail level for the
input.

Horizontal Position (Image)

Specific value

E

X1^

HCTR}

Hctr

X1^

]

Set the horizontal position of
the image in relation to the
center of the screen to

X1^

.

Increment value

E

+ HCTR }

Hctr

X1^

]

Shift image right 1 pixel.

Decrement value

E

- HCTR }

Hctr

X1^

]

Shift image left 1 pixel.

View

E

HCTR}

X1^

]

In verbose modes 2 and 3:
Hctr

X1^

]

View horizontal position value

X1^

.

NOTE:

X1%

= Picture adjustment: 0 through 127 (default = 64)

X1^

= Horizontal or vertical position. Response is 5 digits with leading + or - and padded with zeros.

For DSC 3G-HD A: Range depends on resolution.

For DSC HD-3G A: H range = -02048 – +04096, V range = -01200 – +01200
