Fig_User Presets menu

Figure 16.

User Presets Submenu

In addition to the user presets, 128 global input presets are available via SIS commands
(see the

Presets commands

on page 53). A summary and comparison of the values

stored in user and input presets is shown in the table below.

User Presets

Input Presets

Contrast

H Image

Size

Contrast

H Start

H Image

Position

Brightness

V Image

Size

Brightness

V Start

V Image

Position

Detail

H Image

Position

Detail

H Active

(Pixels)

H Image

Size

Preset

Name

V Image

Position

Film Mode

V Active

(Lines)

V Image

Size

Audio Gain/

Attenuation

Total Pixels

Preset

Name

DSC 3G-HD A and DSC HD-3G A • Operation
