General Operating Principles Switching On
8 BA31114e5 07/2006 BA31114e5 07/2006 9
Operating modes
The OC100 controller has 2 standard operating modes that differ from one another as
described below:
”Routine BOD”
This mode provides the user-friendly ”quick introduction”. The samples are managed
as single samples. The setting functions are logically restricted.
”Standard BOD”
The main difference to the ”Routine BOD” mode is in the parallel sample process for
up to 12 measuring heads per whole sample with mean value formation and statistical
evaluation. The setting is made via the function ”GLP/Tools”. The extended setting
functions allow a multitude of further options (see chapter ”GLP/Tools”). The samples
plotted in the ”Standard BOD” mode are not displayed in the ”Routine BOD” mode.
A table of the settings in the delivery state is given in the chapter ”GLP/Tools”.
Literature
Further information on this subject can be obtained at no cost from WTW:
- BOD handbook
- Application reports
- Special printouts
Controller keyboard
Sample management: List of samples, reading the data of individual
measuring heads or samples, displays of measuring
heads or samples
Printing of measurement data and settings
Switching on/off
GLP / Tools: Display free measuring heads, display or change settings,
perform checks or maintenance
Evaluation: Graphic and numerical display of measuring data
Communication with measuring heads: Start measuring, call up data
Select
Confirmation of entries
