Cal test
The Cal test is used to test the sealing of the system measuring head - rubber
sleeve - sample bottle and the operability of the systems OxiTop
® Control.
In the standard BOD operating mode with the “GLP ON” setting, the controller
indicates when the next Cal test is due after each set up calibration interval (see the
chapter “GLP/Tools - GLP”),.
To perform the test, you need the WTW test resource, OxiTop
® PM, order number
209 333.
Sample preparation: see operating manual, OxiTop
® PM test resource.
“Check“ menu.
Use to select “Cal
test”.
The instrument automatically
allocates the sample number (in
the header line).
The filling volume (164 ml) and
the type together with the run
time of 5 days are preset.
For information on the further handling of the sample up to the “finished” status: See
the chapter “Start”.
The Cal sample appears together with the other samples in the sample management.
The BOD type is “CAL“:
Evaluation of the Cal test
Starting point: sample
management.
Use
to select the test sample.
Enter the evaluation.
Display of the selected sample as
a curve with measurement value
data.
Compare measurement values
with batch test value
(according to operating manual,
OxiTop
® PM).
Now you can set a new
calibration date for the measuring
head with the controller.
- “Show “ (to find the relevant
measuring head):
Function and messages as
described in the chapter
“Sample management“.
- “Set cal date“ (appears only if
the Cal test is finished and the
controller is in the standard
BOD operating mode, GLP is
switched on and the test is
finished).
- see below.
- “Stop“: Return to the curve
display.
In the standard BOD operating mode and GLP “On“:
Use
to select “Set cal date“.
