Operating Mode: Standard BOD Operating Mode: Standard BOD
44 BA31114e5 07/2006 BA31114e5 07/2006 45
Evaluation
Starting point: Sample
management.
Use to select the
sample.
Printout of the results with
curves.
Evaluation of the whole sample:
Display of all the curves together
with mean value data.
Check the display for outliers.
Printout of the results with curves
(according to printing format -
see the chapter “Print“)
Example: Whole sample with
outliers.
Scroll through the parallel
samples: Display of individual
curves (cyclical pass) with data of
the BOD final value.
Printout of a single result with a
single curve.
Sample statistics
Starting point: display of a single
curve.
Changes to sample statistics.
The menu selection shown here
only appears if n (the number of
measuring heads) is at least 2.
If n = 1, see the chapter “Routine
BOD - Evaluation”.
When jumping to the pull-down menu from “Show all curves“, the
menu item “Exclude curve“ disappears.
Results of the finished sample:
Data of the current sample:
- mean value
- SD: standard deviation
(from n = 3)
- n: number of measuring heads
Printout of the results with curves
- end date
- current mean value
- n: number of measuring heads
Printout of the data (current
mean value, n, sample
information) with curve paths to
date
