Function Display Description Default Range
4-6-3. Relay output functions
Output relay 1r
Output relay 2r
Output relay 3r
1 r x x
2 r x x
3 r x x
1 r 2 5
(RUN)
2 r 2 0
(EOR)
3 r 2 2
This is a programmable relay with one NO / NC dry contact to
ASTAT-IBP Plus terminals 11-12-14.
This is a non-programmable relay with one NO dry contact to
ASTAT-IBP Plus terminals 23-24.
This relay is assigned to by-pass control.
This is a programmable relay with one NO dry contact to ASTAT-
IBP Plus's terminals 33-34.
22-30
20
22-30
The programmable relays can be set to the functions shown in the following table:
Function
EOR
FAULT
Undervoltage
Overvoltage
RUN
Undercurrent
Overcurrent
Disabled
Future use
Remarks
Detects end of voltage ramp. This function may only be assigned to relay 2r-
Detects unit Fault status. ON is normal status and switches OFF if a fault occurs
Detects Undervoltage according limit adjusted in function “UV”
Detects Overvoltage according limit adjusted in function “OV”
Detects unit RUN status
Detects Undercurrent according limit adjusted in function “UC”
Detects Overcurrent limits as adjusted in function “OC”
Disables the relay function
Range
20
22
23
24
25
27
28
29
30
4. Programming
4-8
Display
Parameter Parameters (1)
Factory
Default
4-7. Application and basic settings
Nominal motor current N x x x 100
Current limit L x x x 400 375 400
Initial torque T x x x 025 030 035 020 020
Acceleration ramp time a x x x 015 015 030 030 015
Deceleration ramp time d x x x 020 040
Kick start time(2) p x x x 000 100
Soft stop S x x x OFF ON
Pump control C x x x OFF ON
Pump curve starting S T x x 02 02
Pump curve stopping S P x x 02 02
Kick start P x x x OFF ON
Overload trip curve(3) o x x x ooN2 ooN2 ooN2 ooC2 ooC1 ooC1
Service Factor(3) f x x x 100
Compressor Mill Fan
Machine
Tool
Pump
Control
Settings (X X X)
Different applications will require different characteristics and settings for the ASTAT-IBP Plus. The table below lists typical settings for
various applications.
Notes: (1) = GBAS Block Parameters unless noted(2)(3)
(2) = Parameter “p” is disabled while “C” is ON.
(3) = GCAL Block Parameters
